Nibco 1-1/4 inch 125# Bronze Gate Valve, Lead-Free, FIP x FIP

Product image 1

Nibco 1-1/4 inch 125# Bronze Gate Valve, Lead-Free, FIP x FIP

Gate Valve, Lead-Free, T-113-LF Series, Nominal Size: 1-1/4 inch x 1-1/4 inch, FNPT x FNPT Connection, Pressure Rating: 300 psi Non-Shock Cold Working Pressure, Silicon Bronze Body, Non-Rising Alloy Stem, Aramid Fibers with Graphite Packing, Screw-In Silicon Bronze Bonnet, Actuation/Operator: Handwheel, Industry Standards: Conform to MSS SP-80, NSF/ANSI 61 and NSF/ANSI 372, Temperature Rating: 300 Deg F, 2.28 lb Weight, Additional Details: Handwheel Nut: 300 Series Stainless Steel, Identification Plate: Aluminum, Handwheel: Malleable Iron, Packing Nut: Bronze Alloy or Brass, Stuffing Box: Silicon Bronze, Wedge: Silicon Bronze, Packaging: 20/Carton, Dimensions: A: 2.63 inch, B: 5.22 inch, C: 1.19 inch, Class #125

Select Style
From $318.73
Nibco 1-1/4 inch 125# Bronze Gate Valve, Lead-Free, FIP x FIP
$318.73

Product Information

Shipping & Returns

Description

Gate Valve, Lead-Free, T-113-LF Series, Nominal Size: 1-1/4 inch x 1-1/4 inch, FNPT x FNPT Connection, Pressure Rating: 300 psi Non-Shock Cold Working Pressure, Silicon Bronze Body, Non-Rising Alloy Stem, Aramid Fibers with Graphite Packing, Screw-In Silicon Bronze Bonnet, Actuation/Operator: Handwheel, Industry Standards: Conform to MSS SP-80, NSF/ANSI 61 and NSF/ANSI 372, Temperature Rating: 300 Deg F, 2.28 lb Weight, Additional Details: Handwheel Nut: 300 Series Stainless Steel, Identification Plate: Aluminum, Handwheel: Malleable Iron, Packing Nut: Bronze Alloy or Brass, Stuffing Box: Silicon Bronze, Wedge: Silicon Bronze, Packaging: 20/Carton, Dimensions: A: 2.63 inch, B: 5.22 inch, C: 1.19 inch, Class #125
