Mars Direct Drive 3-Speed 1-Phase Reversible Blower Motor, 1075 rpm, 1/2 HP, 208 - 230V

Product image 1

Mars Direct Drive 3-Speed 1-Phase Reversible Blower Motor, 1075 rpm, 1/2 HP, 208 - 230V

The Mars Direct Drive Blower Motor offers 3-speed functionality and a reversible design, ideal for varied ventilation needs. Operating at 1075 rpm with a power of 1/2 HP and voltage range of 208-230V, it suits both professional and DIY applications.

Features:

  • Rheem mounting holes
  • Extended thru bolts shaft end
  • 3 Speed, Single Phase
  • Sleeve Bearing
  • Capacitor required: 7.5 MFD 370V
  • (2)2-1/4 & (2)2-1/2 Resilient Rings
  • Thermal protected, air over
  • 36 inch Leads

Technical Specifications:

  • No. of Poles: 6
  • Motor Type: PSC
  • Enclosure: OAO
  • HP (Max.): 1/2
  • Voltage: 208-230
  • Mounting: Belly Band, Resilient Ring
  • Speeds: 3
  • Hz: 60
  • Rotation: REV
  • RPM Range: 1075
  • NEMA Frame Size: 48
  • Phase: Single
  • Standards: CUL
  • FLA: 3.2
  • Bearing: Sleeve
  • Lead Length: 36 inch
  • Thermal Protection: Auto
  • Ambient Deg C: 40
  • Ins. Class: B
  • Capacitor Included: No
  • Shaft Dia.: 1/2 inch
  • Shaft Length: 4.5 inch
  • Capacitor Rating: 7.5/370
  • Service Factor: 1.0
  • Duty: Continuous
Select Style
From $49.26

Original: $140.74

-65%
Mars Direct Drive 3-Speed 1-Phase Reversible Blower Motor, 1075 rpm, 1/2 HP, 208 - 230V—

$140.74

$49.26

Product Information

Shipping & Returns

Description

The Mars Direct Drive Blower Motor offers 3-speed functionality and a reversible design, ideal for varied ventilation needs. Operating at 1075 rpm with a power of 1/2 HP and voltage range of 208-230V, it suits both professional and DIY applications.

Features:

  • Rheem mounting holes
  • Extended thru bolts shaft end
  • 3 Speed, Single Phase
  • Sleeve Bearing
  • Capacitor required: 7.5 MFD 370V
  • (2)2-1/4 & (2)2-1/2 Resilient Rings
  • Thermal protected, air over
  • 36 inch Leads

Technical Specifications:

  • No. of Poles: 6
  • Motor Type: PSC
  • Enclosure: OAO
  • HP (Max.): 1/2
  • Voltage: 208-230
  • Mounting: Belly Band, Resilient Ring
  • Speeds: 3
  • Hz: 60
  • Rotation: REV
  • RPM Range: 1075
  • NEMA Frame Size: 48
  • Phase: Single
  • Standards: CUL
  • FLA: 3.2
  • Bearing: Sleeve
  • Lead Length: 36 inch
  • Thermal Protection: Auto
  • Ambient Deg C: 40
  • Ins. Class: B
  • Capacitor Included: No
  • Shaft Dia.: 1/2 inch
  • Shaft Length: 4.5 inch
  • Capacitor Rating: 7.5/370
  • Service Factor: 1.0
  • Duty: Continuous
