Designed for high-performance HVAC systems, the Rheem 163S Liquid Line Filter Drier ensures optimal protection and efficiency by filtering out moisture and contaminants before they reach critical system components. With a 3/8-inch sweat ODF connection and uni-directional flow, this filter drier is engineered for compatibility with systems using R-22 and R-410A refrigerants.

Key Features:

• Type: Liquid Line, Uni-Directional
• Connection Size & Type: 3/8 inch, Sweat ODF
• Cubic Capacity: 16 cu. in
• Flow Capacity:
  • 6.2 tons (R-22, AHRI rated)
  • 6.3 tons (R-410A, AHRI rated)
• Maximum Working Pressure: 680 psi
• Minimum Burst Pressure: 1 psi Drop
• Dimensions:
  • Body Length: 4-5/8 inch
  • Overall Length: 6-1/8 inch
  • Diameter: 2-5/8 inch
