Rheem 80 Gallon Light Duty Commercial Tank Water Heater with Terminal Block
Electric Water Heater, Capacity: 80 gal, Fuel Type: Electric, Style: Tall, Type: Light-Duty, Commercial/Residential: Commercial, Phase: Single Phase, Voltage Rating: 277V, Wattage: 12100W, Current Rating: 43.7A, Thermal Efficiency: 0.98, Energy Factor: 0.91 to 0.95, Type Of Element: Resistored Dual Upper and Lower, Number of Elements: 2, Dimensions: 59 inch H x 24-1/2 inch Dia, Temperature Range: 110 to 170 Deg F, Pressure Rating: 150 psi, Material: Stainless Steel, Water Connection Location: Top, Water Connection: 3/4 inch NPT, Warranty: 3 yr for Tank 1 yr for Parts, Includes: Temperature and Pressure Relief Valve, Standards/Approvals: UL Listed, CSA, AHRI Certified, North Carolina And Massachusetts Code Compliant,
Benefits: Available in 208, 240, 277 and 480 voltages; 12.1 kW for 66-120 gallon models. Perfect for High Water Temperature Requirements Greater than 170 F.
Long Life Tank Design: Proprietary steel formulation with a unique coat of high-temperature porcelain enamel maximizes corrosion resistance of the tank. This prolongs the effective life of the anode rod and in turn, the life of the tank.
Long Life Heating Elements: Our patented resistor elements are designed with a specially treated, double layer of magnesium oxide and copper to resist corrosion. Replacement elements screw in easily.
Wiring Options: Simultaneous and non-simultaneous wiring, single-phase and three-phase are available. For Residential applications, convert to non-simultaneous wiring.
Efficient Design: 2-1/2" of rigid polyurethane foam insulation provides superior insulating qualities resulting in reduced operating costs.
Automatic Temperature Control: A surface mounted thermostat automatically cycles on and off to maintain the water temperature at a desired preset level.
Durable Brass Drain Valve: Factory installed brass drain valve allows for faster draining and servicing.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Electric Water Heater, Capacity: 80 gal, Fuel Type: Electric, Style: Tall, Type: Light-Duty, Commercial/Residential: Commercial, Phase: Single Phase, Voltage Rating: 277V, Wattage: 12100W, Current Rating: 43.7A, Thermal Efficiency: 0.98, Energy Factor: 0.91 to 0.95, Type Of Element: Resistored Dual Upper and Lower, Number of Elements: 2, Dimensions: 59 inch H x 24-1/2 inch Dia, Temperature Range: 110 to 170 Deg F, Pressure Rating: 150 psi, Material: Stainless Steel, Water Connection Location: Top, Water Connection: 3/4 inch NPT, Warranty: 3 yr for Tank 1 yr for Parts, Includes: Temperature and Pressure Relief Valve, Standards/Approvals: UL Listed, CSA, AHRI Certified, North Carolina And Massachusetts Code Compliant,
Benefits: Available in 208, 240, 277 and 480 voltages; 12.1 kW for 66-120 gallon models. Perfect for High Water Temperature Requirements Greater than 170 F.
Long Life Tank Design: Proprietary steel formulation with a unique coat of high-temperature porcelain enamel maximizes corrosion resistance of the tank. This prolongs the effective life of the anode rod and in turn, the life of the tank.
Long Life Heating Elements: Our patented resistor elements are designed with a specially treated, double layer of magnesium oxide and copper to resist corrosion. Replacement elements screw in easily.
Wiring Options: Simultaneous and non-simultaneous wiring, single-phase and three-phase are available. For Residential applications, convert to non-simultaneous wiring.
Efficient Design: 2-1/2" of rigid polyurethane foam insulation provides superior insulating qualities resulting in reduced operating costs.
Automatic Temperature Control: A surface mounted thermostat automatically cycles on and off to maintain the water temperature at a desired preset level.
Durable Brass Drain Valve: Factory installed brass drain valve allows for faster draining and servicing.
